GR330-N-CL

Glass/Sash Lock

GR330-N-CL

Premium touchpad, stylish design, number-only smart Glass door lock with trendy sensibility

Opening Method 1-way(Password)
Color
  • Chrome






Dimension & Spec
Type Specification Dimension and Detailed spec.
Installation Environment Tempered Glass Door Door thickness 12mm recommended
Type of product D-NF-T-NK-S DC-Non Fire Resistant-Temperature Sensor-Keyless Type -Rim Lock
Product size Outer Body 69(W) X 178(H) X 22.5(D)mm
Inner Body 75(W) X 179(H) X 39(D)mm
Material Outer Body PC, ABS
Inner Body ALDC, ABS
Components Basic Components -
Optional -
Battery DC 6V 1.5V LR6 AA Alkaline Battery 4pcs
Emergency Power DC 9V Alkaline Battery(sold separately)
DownLoad
User Manual 330 Glass Sash Manual EN.pdf 2020.05.29
Security mode Manual 330 Security mode Manual EN.pdf 2020.05.29
